| PartNumber | NV133FHB-N31 |
| Brand | BOE |
| Size | 13.3 |
| Application | Laptop |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | eDP |
| Diagonal Size | 13.3 inch |
| Pixel Format | 1920(RGB)×1080 [FHD] 166PPI |
| Active Area | 293.76(H)×165.24(V) mm |
| Bezel Area | - |
| Luminance | 0 cd/m² |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Plate Thickness | 0.20+0.20 mm |
| Support Color | 16.7M 72% NTSC |
| Form Style | - |
| Frame Rate | 60Hz |
| D-IC Detail | COG Built-in 4 source chips |
| Interface Type | eDP (2 Lanes) , 30 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Model | NV133FHB-N31 (BOE06E1) |
| Type | a-Si TFT-LCD , CELL |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 298.36(H)×175.29(V) ×0.4(D) mm |
| Treatment | Without Polarizer |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 30 (Typ.)(Tr+Td) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Transmittance | - |
| Light Source | No B/L |
| Designed For | Laptop |
| Touch Panel | Without |
| B133EW04 V0 | AUO | 13.3 | 1280×800 |
| B133EW07 V1 | AUO | 13.3 | 1280×800 |
| B133XW03 V0 | AUO | 13.3 | 1366×768 |
| B133XW03 V1 | AUO | 13.3 | 1366×768 |
| LP133WP1-TJA1 | LG Display | 13.3 | 1440×900 |
| LTN133AT17-W01 | Samsung | 13.3 | 1366×768 |
| LTN133YL01-F01 | Samsung | 13.3 | 3200×1800 |
| N133I5-L01 | Innolux | 13.3 | 1280×800 |
| NV133FHM-N43 | BOE | 13.3 | 1920×1080 |
| NV133FHM-N52 | BOE | 13.3 | 1920×1080 |
