NV133FHM-N33


Brand
BOE
Size
13.3
Application
Laptop
Resolution
1920×1080
Composition
LCM ,   a-Si TFT-LCD
Brightness
CR
800:1
Colors
262K
Backlight
8S4P
Interface
In Stock
16924
Specifications
PartNumber NV133FHM-N33
BrandBOE
Size13.3
ApplicationLaptop
Resolution1920×1080
CompositionLCM ,   a-Si TFT-LCD
Brightness
CR800:1
Colors262K
Backlight8S4P WLED , 15K hours , With LED Driver
Interface
ManufacturerBOE
Screen Size13.3 inch
Pixel Number1920(RGB)×1080   (FHD)  166PPI
Active Area(mm)293.76 × 165.24 (H×V)
Bezel Area(mm)-
Luminance250 (Typ.)(cd/m²)
Viewing Angle85/85/85/85 (Typ.)(CR≥10)
Good View atSymmetry
Color Depth262K   45% NTSC
Outline ShapeSlim (PCBA Flat, T≤3.2mm)
Refresh Rate60Hz
Model NameNV133FHM-N33 (BOE0849)
Screen TypeLCM ,   a-Si TFT-LCD
ArrangementRGB Vertical Stripe
Outline(mm)300.26 × 187.27 × 3 (H×V×D)
TreatmentGlare (Haze 0%), Hard coating (3H)
Contrast Ratio800 : 1 (Typ.) (TM)
Work ModeADS, Normally Black, Transmissive
Response30 (Typ.)(Tr+Td) ms
Used forLaptop
TouchscreenWithout
