| PartNumber | NV156FHM-N4B |
| Brand | BOE |
| Size | 15.6 |
| Application | Laptop Gaming |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Model | NV156FHM-N4B (BOE0726) |
| Diagonal Size | 15.6 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 141PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 344.16(H)×193.59(V) mm |
| Outline Dim. | 359.5(H)×222.8(V) ×3.2(D) mm |
| Bezel Area | - |
| Treatment | Antiglare (Haze 25%) |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 16.4 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | HADS, Normally Black, Transmissive |
| Support Color | 16.7M 100% sRGB |
| Light Source | WLED [9S6P] , 15K hours , With LED Driver |
| Form Style | Slim (PCBA Flat, T≤3.2mm) |
| Designed For | Laptop Gaming |
| Frame Rate | 144Hz |
| Touch Panel | Without |
| Interface Type | eDP (2 Lanes) , HBR2 (5.4G/lane) , 30 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| B156XTN04.5 | AUO | 15.6 | 1366×768 |
| CLAA156WA07A | CPT | 15.6 | 1366×768 |
| LP156WF4-SLC1 | LG Display | 15.6 | 1920×1080 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LTN156HT01-201 | Samsung | 15.6 | 1920×1080 |
| N156BGE-EA1 | Innolux | 15.6 | 1366×768 |
| NT156WHM-N33 | BOE | 15.6 | 1366×768 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
