| PartNumber | P101DEA-AZ0 |
| Brand | Innolux |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 800×1280 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 4 strings WLED , 15K hours , No Driver |
| Interface | MIPI |
| Manufacturer | Innolux |
| Model Name | P101DEA-AZ0 |
| Screen Size | 10.1 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×1280 (WXGA) 150PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 135.36 × 216.576 (H×V) |
| Outline(mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Glare (Haze 0%), Hard coating |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Response | 35 (Max.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 16.7M 60% NTSC |
| Mass | 175g (Max.) |
| Used for | Pad & Tablet |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | MIPI (4 data lanes) , Connector 40 pins |
| Voltage Supply | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| Max. Ratings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
