| PartNumber | QD15TL04 Rev.05 |
| Brand | QDI |
| Size | 15.4 |
| Application | NBPC |
| Resolution | 1280(RGB)×800 , WXGA |
| Composition | LCM |
| Brightness | 165 cd/m² (Typ.) |
| CR | 350:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | QDI |
| Panel Model | QD15TL04 Rev.05 7 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 15.4 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 331.2×207 mm |
| Outline | 344×242.2×6.5 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Glare (Haze 0%), Hard coating (3H), Antireflection |
| Contrast Ratio | 350:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 8/17 (Typ.)(Tr/Td) |
| Viewing Angle | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
| RoHS: |
| B154PW02 V0 | AUO | 15.4 | 1440×900 |
| LP154WX4-TLC8 | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLB2 | LG Display | 15.4 | 1280×800 |
| LTN154CT03-D01 | Samsung | 15.4 | 1920×1200 |
| LTN154P1-L03 | Samsung | 15.4 | 1680×1050 |
| LTN154U2-L03 | Samsung | 15.4 | 1920×1200 |
| LTN154X3-L0D | Samsung | 15.4 | 1280×800 |
| QD15TL04 Rev.04 | QDI | 15.4 | 1280×800 |
| QD15TL04 Rev.05 | QDI | 15.4 | 1280×800 |
| CLAA156WA15A | CPT | 15.6 | 1366×768 |
| G075ADE-T01 | Innolux | 7.5 | 1200×900 |
| LP140WH1-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLL1 | LG Display | 14.0 | 1366×768 |
| LTN121AT08 | Samsung | 12.1 | 1280×800 |
| LTN133AT03-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| LTN133YL01-L01 | Samsung | 13.3 | 3200×1800 |
| LTN173HT02-D02 | Samsung | 17.3 | 1920×1080 |
| LTN173HT02-X01 | Samsung | 17.3 | 1920×1080 |
