| PartNumber | T-51750GD065J-FW-ADN |
| Brand | Kyocera |
| Size | 6.5 |
| Application | IA |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | OPTREX |
| Panel Model | T-51750GD065J-FW-ADN |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 6.5 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 132.48×99.36 mm |
| Outline | 158×120.36 mm |
| Surface | Antiglare (Haze 9%) |
| Contrast Ratio | 300:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193139% |
| Response Time | 15/16 (Typ.)(Tr/Td) |
| Viewing Angle | 55/55/30/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 2 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| Input Voltage | 3.3/5.0V (Typ.)(VCC) |
