| PartNumber | TL079QDXP01 |
| Brand | TIANMA |
| Size | 7.9 |
| Application | Pad & Tablet |
| Resolution | 1536×2048 |
| Composition | LTPS TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Model | TL079QDXP01 |
| Diagonal Size | 7.9 inch |
| Type | LTPS TFT-LCD, LCM |
| Pixel Format | 1536(RGB)×2048 325PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 119.808(H)×159.744(V) mm |
| Outline Dim. | - |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Operating Mode | SFT, Normally Black, Transmissive |
| Support Color | 16.7M 70% NTSC |
| Light Source | WLED |
| Weight | - |
| Designed For | Pad & Tablet |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | MIPI (2 ch, 4 data lanes) Connector |
| Environment | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
