| PartNumber | TM028HDZ58 |
| Brand | TIANMA |
| Size | 2.8 |
| Application | Mobile Phone |
| Resolution | 240×320 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 65K/262K |
| Backlight | 1S4P WLED , No Driver |
| Interface | Parallel |
| Manufacturer | TIANMA |
| Model Name | TM028HDZ58 |
| Screen Size | 2.8 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 240(RGB)×320 (QVGA) 141PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 43.2 × 57.6 (H×V) |
| Outline(mm) | - |
| Luminance | - |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 60/60/60/50 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 65K/262K 55% NTSC |
| Mass | - |
| Used for | Mobile Phone |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | Parallel RGB (1 ch, 6-bit) + SPI |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
