| PartNumber | TM062RDH03 |
| Brand | Tianma |
| Size | 6.2 |
| Application | CNS |
| Resolution | 800(RGB)×480 , WVGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | TIANMA |
| Panel Model | TM062RDH03 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 6.2 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 137.4×77.28 mm |
| Outline | 155.2×88.2×5.2 mm |
| Surface | Antiglare |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193147% |
| Response Time | 20 (Typ.)(Tr+Td) |
| Viewing Angle | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | 3S8PWLEDWithout Driver |
| Signal Interface | TTL (1 ch, 8-bit), 60 pins |
| Input Voltage | 3.3/9.84/19/-7V (Typ.)(AVCC/DVCC/VGH/VGL) |
