| PartNumber | PM062HT1 |
| Brand | E Ink |
| Size | 6.2 |
| Application | IA |
| Resolution | 640(RGB)×240 , HVGA |
| Composition | LCM |
| Brightness | 280 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | PVI |
| Panel Model | PM062HT1 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 6.2 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 148.8×53.76 mm |
| Outline | 173×70×8.9 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 15/25 (Typ.)(Tr/Td) |
| Viewing Angle | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
