| PartNumber | TM084SDHG04 |
| Brand | TIANMA |
| Size | 8.4 |
| Application | Industrial |
| Resolution | 800(RGB)×600, SVGA, 119PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | 8S3P |
| Interface | LVDS |
| Panel Brand | TIANMA |
| Panel Model | TM084SDHG04 |
| Panel Size | 8.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 170.4(W)×127.8(H) mm |
| Bezel Opening | 173.0(W)×130.6(H) mm |
| Outline Size | 203(W)×143.5(H) ×7.05(D) mm |
| Surface | Antiglare |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 12 o'clock |
| Response Time | 20 (Typ.)(Tr+Td) |
| Display Colors | 262K 40% NTSC |
| Lamp Type | 8S3P WLED , 30K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 240g (Typ.) |
| Signal Interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
