| PartNumber | TV080WUM-AK1 |
| Brand | BOE |
| Size | 8.0 |
| Application | Pad & Tablet |
| Resolution | 1200(RGB)×1920, WUXGA, 283PPI |
| Composition | a-Si TFT-LCD , Assem |
| Brightness | 350 cd/m² (Typ.) |
| CR | 850:1 |
| Colors | 16.7M |
| Backlight | 7S3P |
| Interface | |
| Panel Brand | BOE |
| Panel Size | 8.0" |
| Display Area | 107.64(W)×172.224(H) mm |
| Outline Size | 122.2(W)×210.95(H) ×3.95(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 63% NTSC |
| Frequency | 60Hz |
| Weight | 130g (Max.) |
| Panel Model | TV080WUM-AK1 |
| Panel Type | a-Si TFT-LCD , Assembly |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | - |
| Contrast Ratio | 850:1 (Typ.) (TM) |
| Display Mode | - |
| Response Time | 25 (Typ.)(Tr+Td) |
| Lamp Type | 7S3P WLED , 15K hours , Without Driver |
| Touch Screen | PCAP, Optical Bonding |
| A080SN03 V3 | AUO | 8.0 | 800×600 |
| A080XN01 V1 | AUO | 8.0 | 1024×768 |
| AT080TN01 | Innolux | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| EC080SC2 | E Ink | 8.0 | |
| LQ080Y5DZ03 | SHARP | 8.0 | 800×480 |
| LSL080AL02-002 | Samsung | 8.0 | 800×1280 |
| N080JCE-G41 | Innolux | 8.0 | 1200×1920 |
| TV080WXM-NL0 | BOE | 8.0 | 800×1280 |
| TX20D16VM2BAA | KOE | 8.0 | 800×480 |
