| PartNumber | TV101WUB-NV0 |
| Brand | BOE |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 1200×1920 |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | MIPI |
| Model | TV101WUB-NV0 |
| Diagonal Size | 10.1 inch |
| Type | a-Si TFT-LCD, CELL |
| Pixel Format | 1200(RGB)×1920 [WUXGA] 225PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 135.36(H)×216.576(V) mm |
| Outline Dim. | 140.26(H)×225.346(V) ×0.8(D) mm |
| Luminance | 0 cd/m² |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Plate Thickness | 0.25+0.25 mm |
| Transmittance | 5.1% (Typ.)(with Polarizer) |
| Support Color | 16.7M 71% NTSC |
| Light Source | No B/L |
| Weight | - |
| Designed For | Pad & Tablet |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| D-IC Detail | COG Built-in 2 source chips |
| Interface Type | MIPI (4 data lanes) , 44 pins Connector |
| Power Supply | 3.3/9.8/4.8V (Typ.)(VDDI/AVDD/HAVDD) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
