V260B3-LE1


Brand
Innolux
Size
26.0
Application
LCTV
Resolution
1366×768
Composition
LCM
Brightness
400
CR
3000:1
Colors
16.7M
Backlight
WLED
Interface
LVDS
In Stock
7405
Specifications
PartNumber V260B3-LE1
BrandInnolux
Size26.0
ApplicationLCTV
Resolution1366(RGB)×768 , WXGA
CompositionLCM
Brightness400 cd/m² (Typ.)
CR3000:1
Colors16.7M
BacklightWLED
InterfaceLVDS
Panel BrandCMO
Panel ModelV260B3-LE1
Panel Type a-Si TFT-LCD , LCM
Panel Size26.0 inch
Display ModeMVA, Normally Black, Transmissive
Active Area575.769×323.712 mm
Outline613×361 mm
SurfaceAntiglare (Haze 11%), Hard coating (3H)
Contrast Ratio3000:1 (Typ.)
Display Colors16.7M (8-bit), CIE193172%
Response Time8.5 (Typ.)(G to G)
Viewing Angle88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
Frequency60Hz
Lamp TypeWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Voltage12.0V (Typ.)
Family Model
V260B1-L01 Innolux 26.0 1366×768
V260B1-L02 Innolux 26.0 1366×768
V260B1-L03 Innolux 26.0 1366×768
V260B1-L11 Innolux 26.0 1366×768
V260B2-L01 Innolux 26.0 1366×768
V260B2-L04 Innolux 26.0 1366×768
V260B3-L01 Innolux 26.0 1366×768
V260B3-L07 Innolux 26.0 1366×768
V260B3-LE1 Innolux 26.0 1366×768
V260B3-LE2 Innolux 26.0 1366×768
