V460H1-LS1 Rev.C6

V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6 thumb V460H1-LS1 Rev.C6 thumb V460H1-LS1 Rev.C6 thumb
Brand
Innolux
Size
46
Application
LCTV
Resolution
1920×1080
Composition
LCM
Brightness
350
CR
6000:1
Colors
1.07B
Backlight
WLED
Interface
LVDS
In Stock
19025
Specifications
PartNumber V460H1-LS1 Rev.C6
BrandInnolux
Size46
ApplicationLCTV
Resolution1920(RGB)×1080 , FHD
CompositionLCM
Brightness350 cd/m² (Typ.)
CR6000:1
Colors1.07B
BacklightWLED
InterfaceLVDS
Panel BrandCHIMEI INNOLUX
Panel ModelV460H1-LS1 Rev.C6
Panel Type a-Si TFT-LCD , LCM
Panel Size46 inch
Display ModeSuper MVA, Normally Black, Transmissive
Active Area1018.08×572.67 mm
Outline1076.5×634.7 mm
SurfaceAntiglare (Haze 11%), Hard coating (3H)
Contrast Ratio6000:1 (Typ.)
Display Colors1.07B (8-bit + Hi-FRC), CIE193172%
Response Time6 (Typ.)(G to G)
Viewing Angle88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
Frequency120Hz
Lamp Type4 stringsWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 10-bit), 102 pins
Input Voltage12.0V (Typ.)
