| PartNumber | V460H1-L09 |
| Brand | Innolux |
| Size | 46 |
| Application | LCTV |
| Resolution | 1920(RGB)×1080 , FHD |
| Composition | LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 6000:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | CHIMEI INNOLUX |
| Panel Model | V460H1-L09 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 46 inch |
| Display Mode | Super MVA, Normally Black, Transmissive |
| Active Area | 1018.08×572.67 mm |
| Outline | 1083×627 mm |
| Surface | Antiglare (Haze 11%), Hard coating (3H) |
| Contrast Ratio | 6000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 6.5 (Typ.)(G to G) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 14 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Input Voltage | 12.0V (Typ.) |
| LTY460HH-LH2 | Samsung | 46 | 1920×1080 |
| V460H1-L09 | Innolux | 46 | 1920×1080 |
| V460H1-L12 | Innolux | 46 | 1920×1080 |
| V460H1-LE3 | Innolux | 46 | 1920×1080 |
| V460H1-LH9 | Innolux | 46 | 1920×1080 |
| V460H1-LS1 | Innolux | 46 | 1920×1080 |
| V460H1-LS1 Rev.C6 | Innolux | 46 | 1920×1080 |
| V460H1-LS2 | Innolux | 46 | 1920×1080 |
| V460H1-LS2 Rev.C7 | Innolux | 46 | 1920×1080 |
| V460HK2-LS5 | Innolux | 46 | 1920×1080 |
| LC420EUN-SFM1 | LG Display | 42 | 1920×1080 |
| LC500DUE-VGM1 | LG Display | 50 | 1920×1080 |
| LC550EUN-PFF1 | LG Display | 55 | 1920×1080 |
| LTA520HB03-001 | Samsung | 52 | 1920×1080 |
| LTY400HC01 | Samsung | 40 | 1920×1080 |
| T390XVN01.0 CELL | AUO | 39 | 1366×768 |
| T500HVD01.0 | AUO | 50 | 1920×1080 |
| T500HVN01.0 | AUO | 50 | 1920×1080 |
| V420H1-LH4 | Innolux | 42 | 1920×1080 |
| V420H2-L05 | Innolux | 42 | 1920×1080 |
