V460H1-LS2 Rev.C7

V460H1-LS2 Rev.C7
V460H1-LS2 Rev.C7
V460H1-LS2 Rev.C7 thumb V460H1-LS2 Rev.C7 thumb
Brand
Innolux
Size
46
Application
LCTV
Resolution
1920×1080
Composition
LCM
Brightness
370
CR
5000:1
Colors
16.7M
Backlight
WLED
Interface
LVDS
In Stock
19
Specifications
PartNumber V460H1-LS2 Rev.C7
BrandInnolux
Size46
ApplicationLCTV
Resolution1920(RGB)×1080 , FHD
CompositionLCM
Brightness370 cd/m² (Typ.)
CR5000:1
Colors16.7M
BacklightWLED
InterfaceLVDS
Panel BrandCHIMEI INNOLUX
Panel ModelV460H1-LS2 Rev.C7
Panel Type a-Si TFT-LCD , LCM
Panel Size46 inch
Display ModeSuper MVA, Normally Black, Transmissive
Active Area1018.08×572.67 mm
Outline1056.9×612.3 mm
SurfaceAntiglare (Haze 11%), Hard coating
Contrast Ratio5000:1 (Typ.)
Display Colors16.7M (8-bit), CIE193172%
Response Time6 (Typ.)(G to G)
Viewing Angle88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
Frequency120Hz (60Hz Input)
Lamp TypeWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 10-bit), 61 pins
Input Voltage12.0V (Typ.)
Family Model
LTY460HQ05-A01 Samsung 46 1920×1080
T460HW03 VB AUO 46 1920×1080
V460H1-L09 Innolux 46 1920×1080
V460H1-L12 Innolux 46 1920×1080
V460H1-LE3 Innolux 46 1920×1080
V460H1-LH9 Innolux 46 1920×1080
V460H1-LS1 Innolux 46 1920×1080
V460H1-LS1 Rev.C6 Innolux 46 1920×1080
V460H1-LS2 Innolux 46 1920×1080
V460H1-LS2 Rev.C7 Innolux 46 1920×1080
