| PartNumber | VTF231BJ02 |
| Brand | BOE |
| Size | 23.1 |
| Application | Digital Signage Stretched Bar LCD |
| Resolution | 1920×158(RGB), 83PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | BOE |
| Panel Model | VTF231BJ02 |
| Panel Size | 23.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Horizontal Stripe |
| Display Area | 585.216(W)×48.158(H) mm |
| Bezel Opening | 587.5(W)×49.8(H) mm |
| Outline Size | 597.2(W)×60.2(H) ×17.1(D) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 15 (Typ.)(G to G) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | WLED , 30K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 450g (Typ.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
