| PartNumber | WF35NTVAJDNN0 |
| Brand | Winstar |
| Size | 3.5 |
| Application | Industrial Automotiv |
| Resolution | 240×320 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 900:1 |
| Colors | Grayscale |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 3.5 inch |
| Pixel Format | 240×320 [QVGA] 114PPI |
| Active Area | 53.28(H)×71.04(V) mm |
| Bezel Area | 56.16(H)×73.04(V) mm |
| Luminance | 500 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | - |
| Support Color | Grayscale |
| Weight | - |
| Frame Rate | - |
| Model | WF35NTVAJDNN0 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | Rectangle |
| Outline Dim. | 62.9(H)×86.5(V) ×4.1(D) mm |
| Treatment | Glare (Haze 0%) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Response Time | - |
| Operating Mode | VA, Normally Black, Transmissive |
| Light Source | WLED , W/O Driver |
| Designed For | Industrial Automotive Display |
| Touch Panel | Without |
| 35HVE1H | SII | 3.5 | 320×480 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| GPM782A0 | Giantplus | 3.5 | 320×240 |
| H347QN02 V0 | AUO | 3.5 | 320×480 |
| LMS350GF08 | Samsung | 3.5 | 320×240 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| LTJ035L001A | TPO | 3.5 | 640×360 |
| T-51963GD035J-MLW-AJN | Kyocera | 3.5 | 240×320 |
| TX09D200VM0BAA | KOE | 3.5 | 240×320 |
