| PartNumber | A062EAN01.0 |
| Brand | AUO |
| Size | 6.2 |
| Application | Home Appliance |
| Resolution | 1280×720 |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | |
| Diagonal Size | 6.2 inch |
| Pixel Format | 1280(RGB)×720 [WXGA] 237PPI |
| Active Area | 137.088(H)×77.112(V) mm |
| Bezel Area | - |
| Luminance | 0 cd/m² |
| View Direction | Symmetry |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Plate Thickness | 0.20+0.20 mm |
| Support Color | 16.7M 71% NTSC |
| Weight | TBD |
| Frame Rate | 60Hz |
| D-IC Detail | COG Suggest HX8394-F |
| Environment | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
| Model | A062EAN01.0 |
| Type | a-Si TFT-LCD , CELL |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 145.338(H)×81.712(V) ×0.63(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 15/12 (Typ.)(Tr/Td) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Transmittance | 4.64% (Typ.)(with Polarizer) |
| Light Source | No B/L |
| Designed For | Home Appliance |
| Touch Panel | Without |
