| PartNumber | B173ZAN01.1 |
| Brand | AUO |
| Size | 17.3 |
| Application | Laptop |
| Resolution | 3840×2160 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED , 15K hours , With LED Driver |
| Interface | eDP |
| Manufacturer | AUO |
| Screen Size | 17.3 inch |
| Pixel Number | 3840(RGB)×2160 (UHD) 255PPI |
| Active Area(mm) | 382.12 × 214.94 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 300 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 100% Adobe RGB |
| Outline Shape | Flat (PCBA Flat, T3.4~4.0mm) |
| Refresh Rate | 60Hz |
| Signal Type | eDP (4 Lanes) , eDP1.3 , 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | B173ZAN01.1 (AUO119B) |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 398.1 × 252.5 × 4 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Response | 27 (Typ.)(Tr+Td) ms |
| Work Mode | AHVA, Normally Black, Transmissive |
| Used for | Laptop |
| Touchscreen | Without |
