| PartNumber | CLAA185WA03 |
| Brand | CPT |
| Size | 18.5 |
| Application | DMPC |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | CPT |
| Panel Model | CLAA185WA03 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 18.5 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 409.8×230.4 mm |
| Outline | 430.37×254.6×17 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Response Time | 5 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/75 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 2 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Voltage | 5.0V (Typ.) |
| CLAA101WA01 | CPT | 10.1 | 1366×768 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| CLAA141WB05A | CPT | 14.1 | 1280×800 |
| CLAA150XP01Q V2 | CPT | 15.0 | 1024×768 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| CLAA154WP05A | CPT | 15.4 | 1440×900 |
| CLAA156WA07A | CPT | 15.6 | 1366×768 |
| CLAA170EA07 | CPT | 17.0 | 1280×1024 |
| CLAA170ES01E | CPT | 17.0 | 1280×1024 |
| CLAA184FP01 | CPT | 18.4 | 1920×1080 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| HSD170MGW1-B01 | HannStar | 17.0 | 1440×900 |
| LM150X08-TL01 | LG Display | 15.0 | 1024×768 |
| LM190WX2-TLK1 | LG Display | 19.0 | 1440×900 |
| LTM200KT10 | Samsung | 20.0 | 1600×900 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| M170EG01 V8 | AUO | 17.0 | 1280×1024 |
| M170EN04 V6 | AUO | 17.0 | 1280×1024 |
| M215HNE-L30 | Innolux | 21.5 | 1920×1080 |
| NA19020-C262 | Fujitsu | 15.0 | 1024×768 |
