| PartNumber | CLAF058LA31 |
| Brand | CPT |
| Size | 5.8 |
| Application | MPH |
| Resolution | 540(RGB)×960 , qHD |
| Composition | CELL |
| Brightness | 0 |
| CR | 900:1 |
| Colors | |
| Backlight | No B/L |
| Interface | |
| Panel Brand | CPT |
| Panel Model | CLAF058LA31 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 5.8 inch |
| Display Mode | VA, Normally Black, Transmissive |
| Active Area | 72.09×128.16 mm |
| Outline | 75.69×137.86×0.5 mm |
| Surface | Without Polarizer |
| Glass Depth | 0.25+0.25 mm |
| Transmissivity | 4.7% (Typ.)(with Polarizer) |
| Contrast Ratio | 900:1 (Typ.) |
| Display Colors | |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Driver IC | COG Suggest HX8389-B |
