| PartNumber | CLAP070WP03XG |
| Brand | CPT |
| Size | 7.0 |
| Application | PAD |
| Resolution | 800(RGB)×1280 , WXGA |
| Composition | CELL |
| Brightness | 0 |
| CR | 700:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | LVDS |
| Panel Brand | CPT |
| Panel Model | CLAP070WP03XG |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 7.0 inch |
| Display Mode | HFFS, Normally Black, Transmissive |
| Active Area | 94.2×150.72 mm |
| Outline | 102.1×158.92×0.87 mm |
| Surface | |
| Glass Depth | 0.30+0.30 mm |
| Transmissivity | 3.66% (Typ.)(with Polarizer) |
| Contrast Ratio | 700:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 50 (Max.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (1 ch, 8-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
| A070VW08 V2 | AUO | 7.0 | 800×480 |
| C070VW01 V0 | AUO | 7.0 | 800×480 |
| CLAA070JA1BCW | CPT | 7.0 | 480×234 |
| CLAP070WP03XG | CPT | 7.0 | 800×1280 |
| HV070WX2-100 | HYDIS | 7.0 | 800×1280 |
| LB070WV1-TD08 | LG Display | 7.0 | 800×480 |
| LMS700KF07 | Samsung | 7.0 | 800×480 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
| LW700AT9003 | Innolux | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| LTL106HL02-001 | Samsung | 10.6 | 1920×1080 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| TFTMD070021 | JDI | 7.0 | 1200×1920 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
