| PartNumber | ES050YMM-A00 |
| Brand | BOE |
| Size | 5.0 |
| Application | Round Display Instru |
| Resolution | 1080×1080 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1300:1 |
| Colors | 16.7M |
| Backlight | WLED , No Driver |
| Interface | |
| Manufacturer | BOE |
| Model Name | ES050YMM-A00 |
| Screen Size | 5.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1080(RGB)×1080 215PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 127.008 × 127.008 (H×V) |
| Outline(mm) | 143 × 140 × 4.45 (H×V×D) |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 1300 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 40 (Max.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 80% NTSC |
| Mass | - |
| Used for | Round Display Instruments & Meters Home Appliance |
| Refresh Rate | 60Hz |
| Touchscreen | PCAP |
| Storage Temp.: -30 ~ 75 °C Operating Temp.: -20 ~ 60 °C |
| A050BTS30R0 | Aptus | 5.0 | 480×480 |
| COM50H5125XLC | ORTUSTECH | 5.0 | 320×240 |
| DLC0500EZG-T-6 | Other | 5.0 | 800×480 |
| LH500WF1-SD02 | LG Display | 5.0 | 1080×1920 |
| LQ050Q5DR01 | SHARP | 5.0 | 320×240 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| LQ050T5DW02 | SHARP | 5.0 | 400×240 |
| LQ5AW136R | SHARP | 5.0 | 320×234 |
| PW050XS3 | E Ink | 5.0 | 320×220 |
| ZJ050NA-08C | Innolux | 5.0 | 640×480 |
