| PartNumber | PW050XS3 |
| Brand | E Ink |
| Size | 5.0 |
| Application | CNS |
| Resolution | 320(RGB)×220 |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 350:1 |
| Colors | Full color |
| Backlight | CCFL |
| Interface | Analog |
| Panel Brand | PVI |
| Panel Model | PW050XS3 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 5.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 112.5×60.5 mm |
| Outline | 125.4×74×6.5 mm |
| Surface | Antiglare |
| Contrast Ratio | 350:1 (Typ.) |
| Display Colors | Full color |
| Response Time | 15/30 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/50/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 30 pins |
| Input Voltage | 3.3/3.3/5.0/15.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| AT050TN43 V.1 | Innolux | 5.0 | 800×480 |
| BTL507212-W677L | BOE | 5.0 | 720×1280 |
| EE050NA-04A | Innolux | 5.0 | 640×480 |
| EJ050NA-01G | Innolux | 5.0 | 800×480 |
| H495TAN01.1 | AUO | 5.0 | 720×1280 |
| H497DAN01.0 | AUO | 5.0 | 1080×1920 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| PW050XS3 | E Ink | 5.0 | 320×220 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| TFD50W52MS3 | TOSHIBA | 5.0 |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| C065GW02 V1 | AUO | 6.5 | 400×234 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LQ058T5DG30 | SHARP | 5.8 | 480×240 |
| LQ065Y5DZ01 | SHARP | 6.5 | 800×480 |
| LQ5AW136R | SHARP | 5.0 | 320×234 |
| PA050DS7N1 | E Ink | 5.0 | 320×234 |
| PA064XS2 | E Ink | 6.4 | 320×234 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
