| PartNumber | ETM057010EDHU |
| Brand | EDT |
| Size | 5.7 |
| Application | Industrial |
| Resolution | 640(RGB)×480, VGA, 141PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 380 cd/m² (Typ.) |
| CR | 350:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | Parallel |
| Panel Brand | EDT |
| Panel Model | ETM057010EDHU |
| Panel Size | 5.7" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 115.2(W)×86.4(H) mm |
| Bezel Opening | - |
| Outline Size | 147.6(W)×100(H) ×11.7(D) mm |
| Surface | - |
| Contrast Ratio | 350:1 (Typ.) (TM) |
| Viewing Angle | 65/65/55/52 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 12 o'clock |
| Response Time | 15/35 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 51% NTSC |
| Lamp Type | WLED , 30K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | PCAP |
| Panel Weight | - |
| Signal Interface | Parallel RGB (1 ch, 8-bit) , 40 pins Connector |
| Input Voltage | 3.3/3.3V (Typ.)(VCC/VDD) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AA057VF12 | Mitsubishi | 5.7 | 640×480 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| EL320.240.36 HB NE | PLANAR | 5.7 | 320×240 |
| ER0570B2NC6 | EDT | 5.7 | 320×240 |
| H572DAN01.2 | AUO | 5.7 | 1080×1920 |
| KG057QV1CA-G020W | Kyocera | 5.7 | 320×240 |
| LQ057Q3DG02 | SHARP | 5.7 | 320×240 |
| LQ057V3DG01 | SHARP | 5.7 | 640×480 |
| T78AAVGTF0 | Other | 5.7 | 320×240 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
