| PartNumber | GV101WXB-NZ1-DGP0 |
| Brand | BOE |
| Size | 10.1 |
| Application | Industrial |
| Resolution | 1280×800 |
| Composition | CELL, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No B/L , With LED Driver |
| Interface | |
| Manufacturer | BOE |
| Model Name | GV101WXB-NZ1-DGP0 |
| Screen Size | 10.1 inch |
| Screen Type | CELL, a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×800 (WXGA) 149PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 216.96 × 135.6 (H×V) |
| Outline(mm) | 221.96 × 144.43 × 1.06 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Without Polarizer, Hard coating |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 35 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 50% NTSC |
| Mass | - |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| HE101NA-02C | Innolux | 10.1 | 1280×800 |
| HSD101PFW1-A01 | HannStar | 10.1 | 1024×576 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
| TT101WSQ-N10 | BOE | 10.1 | 1024×600 |
