| PartNumber | LTM15C428S |
| Brand | TOSHIBA |
| Size | 15.0 |
| Application | DMPC |
| Resolution | 1024(RGB)×768 , XGA |
| Composition | LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 250:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TMDS |
| Panel Brand | TOSHIBA |
| Panel Model | LTM15C428S |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 15.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 304.128×228.096 mm |
| Outline | 336×249×13.5 mm |
| Surface | |
| Contrast Ratio | 250:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193162% |
| Response Time | 40/10 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 2 pcsCCFLWithout Driver |
| Signal Interface | Single Link TMDS, 20 pins |
| Input Voltage | 3.3V (Typ.) |
