| PartNumber | M220Z1-P03 |
| Brand | Innolux |
| Size | 22.0 |
| Application | DMPC |
| Resolution | 1680(RGB)×1050 , WSXGA+ |
| Composition | CELL |
| Brightness | 0 |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | LVDS |
| Panel Brand | CMO |
| Panel Model | M220Z1-P03 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 22.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 473.76×296.1 mm |
| Outline | 485.26×307.6 mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Glass Depth | 0.70+0.70 mm |
| Transmissivity | 5.8% (Typ.)(with Polarizer) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 1.3/3.7 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Voltage | 5.0V (Typ.) |
