| PartNumber | NL160120BC27-14 |
| Brand | NLT |
| Size | 21.3 |
| Application | DMPC |
| Resolution | 1600(RGB)×1200 , UXGA |
| Composition | LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 550:1 |
| Colors | 16.7M |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | NEC |
| Panel Model | NL160120BC27-14 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 21.3 inch |
| Display Mode | SA-SFT, Normally Black, Transmissive |
| Active Area | 432×324 mm |
| Outline | 457×350 mm |
| Surface | Antiglare, Hard coating (2H) |
| Contrast Ratio | 550:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193172% |
| Response Time | 11/9 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 40 pins |
| Input Voltage | 12.0V (Typ.) |
