| PartNumber | QV101WUB-N80 |
| Brand | BOE |
| Size | 10.1 |
| Application | Industrial |
| Resolution | 1920×1200 |
| Composition | CELL , a-Si TFT-LC |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | |
| Manufacturer | BOE |
| Screen Size | 10.1 inch |
| Pixel Number | 1920(RGB)×1200 (WUXGA) 224PPI |
| Active Area(mm) | 216.806 × 135.504 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 0 (cd/m²) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Glass Thickness | - |
| Color Depth | 16.7M 72% NTSC |
| Mass | - |
| Refresh Rate | 60Hz |
| Model Name | QV101WUB-N80 |
| Screen Type | CELL , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 221.81 × 145.5 (H×V×D) |
| Treatment | Hard coating |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Work Mode | ADS, Normally Black, Transmissive |
| Response | 30 (Typ.)(Tr+Td) ms |
| Transmissivity | 3.85% (Typ.)(with Polarizer) |
| Used for | Industrial |
| Touchscreen | Without |
