| PartNumber | TV097QXM-NW0 |
| Brand | BOE |
| Size | 9.7 |
| Application | Pad & Tablet |
| Resolution | 1536(RGB)×2048, QXGA, 264PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | 6S6P |
| Interface | MIPI |
| Panel Brand | BOE |
| Panel Model | TV097QXM-NW0 |
| Panel Size | 9.7" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 147.456(W)×196.608(H) mm |
| Bezel Opening | - |
| Outline Size | 152.536(W)×206.548(H) ×4.5(D) mm |
| Surface | - |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 35 (Max.)(Tr+Td) |
| Display Colors | 16.7M 70% NTSC |
| Lamp Type | 6S6P WLED , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 135g (Max.) |
| Signal Interface | MIPI (4 data lanes) , 61 pins Connector |
| Input Voltage | 1.8/5.5/-5.5V (Typ.)(VDDI/AVDD/AVEE) |
| Environment | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
