| PartNumber | KHS038AA1AA-B70R |
| Brand | Kyocera |
| Size | 3.8 |
| Application | Industrial |
| Resolution | 240×320 |
| Composition | CSTN-LCD, LCM |
| Brightness | |
| CR | |
| Colors | Color |
| Backlight | CCFL |
| Interface | Parallel |
| Model | KHS038AA1AA-B70R |
| Diagonal Size | 3.8 inch |
| Type | CSTN-LCD, LCM |
| Pixel Format | 240(RGB)×320 [QVGA] 105PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 57.58(H)×76.78(V) mm |
| Outline Dim. | - |
| View Direction | - |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | STN, Normally Black, Reflective |
| Support Color | Color |
| Light Source | CCFL [1 pcs] |
| Weight | - |
| Designed For | Industrial |
| Interface Type | Parallel Data (1ch, 8-bit) FPC |
| Power Supply | 3.3V (Typ.) |
| H380VW01 V2 | AUO | 3.8 | 480×800 |
| H381DLN01.0 | AUO | 3.8 | 1080×1200 |
| KCS038AA1AG-G21 | Kyocera | 3.8 | 240×320 |
| KHS038AA1AA-B70R-57-11 | Kyocera | 3.8 | 240×320 |
| LQ038B3DD01 | SHARP | 3.8 | 320×480 |
| LQ038Q5DR01 | SHARP | 3.8 | 320×240 |
| LS038Y7DX01 | SHARP | 3.8 | 480×800 |
| SP10Q010 | KOE | 3.8 | 320×240 |
| TM038QV-67A02E | SANYO | 3.8 | 320×240 |
| TM038QV-67A03 | SANYO | 3.8 | 320×240 |
