| PartNumber | M140NWF7 R2 |
| Brand | IVO |
| Size | 14.0 |
| Application | Laptop Gaming |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 600:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Diagonal Size | 14.0 inch |
| Pixel Format | 1920(RGB)×1080 [FHD] 157PPI |
| Active Area | 309.31(H)×173.99(V) mm |
| Bezel Area | - |
| Luminance | 400 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 16.7M 72% NTSC |
| Form Style | Slim (PCBA Bent, T≤3.0mm) |
| Frame Rate | 120Hz |
| Interface Type | eDP (4 Lanes) , eDP1.3 , 40 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 70 °C |
| Model | M140NWF7 R2 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 315.61(H)×186.39(V) ×3.9(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Light Source | WLED , 15K hours , With LED Driver |
| Designed For | Laptop Gaming |
| Touch Panel | Without |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| B140XTT01.0 | AUO | 14.0 | 1366×768 |
| B140XW01 V4 | AUO | 14.0 | 1366×768 |
| HB140WX1-501 | BOE | 14.0 | 1366×768 |
| LTN140AT20-L01 | Samsung | 14.0 | 1366×768 |
| M140NWR1 R0 | IVO | 14.0 | 1366×768 |
| M140NWR2 R0 | IVO | 14.0 | 1366×768 |
| M140NWR2 R1 | IVO | 14.0 | 1366×768 |
| M140NWR2 R2 | IVO | 14.0 | 1366×768 |
| M140NWR4 R2 | IVO | 14.0 | 1366×768 |
