| PartNumber | TX18D212VM0BAA |
| Brand | KOE |
| Size | 7.0 |
| Application | Industrial Outdoor H |
| Resolution | 1280×768 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 7.0 inch |
| Pixel Format | 1280(RGB)×768 [WXGA] 213PPI |
| Active Area | 152.448(H)×91.4688(V) mm |
| Bezel Area | 154.5(H)×93.5(V) mm |
| Luminance | 1000 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 16.7M 72% NTSC |
| Weight | 212g (Typ.) |
| Frame Rate | 60Hz |
| Model | TX18D212VM0BAA |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 164.4(H)×105(V) ×13.5(D) mm |
| Treatment | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | 25 (Max.)(Tr+Tf) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Light Source | WLED , 50K hours , With LED Driver |
| Designed For | Industrial Outdoor High Brightness |
| Touch Panel | Without |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| BP070WSA-400 | BOE | 7.0 | 1024×600 |
| EJ070NA-01J | Innolux | 7.0 | 1024×600 |
| G070VW01 V1 | AUO | 7.0 | 800×480 |
| HE070IA-04F | Innolux | 7.0 | 800×1280 |
| LB070WV4-TJ01 | LG Display | 7.0 | 800×480 |
| LMS700KF07 | Samsung | 7.0 | 800×480 |
| LQ7BW566AH | SHARP | 7.0 | 480×234 |
| LTP700WV-F01 | Samsung | 7.0 | 800×480 |
| VVX07H005A90 | Panasonic | 7.0 | 800×1280 |
